High Efficiency 440 Watt Solar Cell Panel Mono Photovoltaic Module
Solar Cell Panel Parameters
Rated Maximum Power (Pmax) 440W
Tolerance 0→10 W
Voltage at Pmax (Vmp) 41.0V
Current at Pmax iimp) 10.7AA
Open-Circuit Voltage (Voe) 49.6 V
Short-Cireult current (lsc) 11.33A
Maximum System Voltage 1500V
Maximum Series Fuse Rating 20A
Operating Temperature40rC+a*C
| Name: | Solar Cell Panel | Rated Maximum Power (Pmax): | 440W |
|---|
| Current At Pmax Iimp): | 10.7AA | Tolerance: | 0→10 W |
|---|
| Voltage At Pmax (Vmp): | 41.0V | Customized Service: | Yes |
|---|
| Material: | Monocrystalline Silicon | Color: | Blue/Black |
|---|
Solar Cell Panel Details
GLASS
The glass surface is coated with a closed-cell nanostructure to
improve the transparency, reliability and anti-fouling properties
of the components
ALUMINUM FRAME
The first-class surface treatment technology and structural design
ensure excellent corrosion resistance and mechanical strength, high
resistance to salt and ammonia corrosion
TERMINAL BLOCK
The shell has good anti-aging and uv resistance, and the design of
sealed junction box ensures good sealing, which meets the
requirements of harsh outdoor environment
Packing Details :
Packing Wooden Carton
1*20' GP 6Pallets/240pcs
1*40'HQ 14Pallets/644pcs
FAQ
Q1: What is your MOQ?
A: We have no MOQ, 1pc sample order is also ok for us,but best Cost
performance is by big quantity order.
Q2: Do you have any experience with big bidding projects?
A: Yes, we have rich experience on the big bidding projects, and
have helped our customers win many such bidding projects. Our sale
engineer are very familiar with the bidding procedure and can
provide detailed information as required in time.
Q3: Do you accept OEM?
A: yes, we can do the OEM for you, and we are the OEM supplier of
many famous brands from Europe, USA, Asia,Middle East and Africa
etc.
Q4: What payment terms do you accept?
A: We accept TT, LC,Cash, and Western Union etc.
Q5: What about the production time?
A: Samples can be delivery at once
500sets above normal need 10 to 15 days, if no goods in storage.
2000sets above normal need 15 to 20 days, if no goods in storage.
Q6: What else materials should we prepare before installation after
buying your solar panels?
A: We can provide all system components and only small civil work
is needed
Q7: What is your Warranty Policy?
A: We offer 20 years warranty for the entire system and can be
replaced with new ones for free if quality Issues.
