18.3 Kg Second Hand Yingli Solar Panels 1640 × 990 × 35 Mm Format

Csun Poly Solar Panel 265W 270W with Yingli Solar Cell for Home Electricity

Product Description

MECHANICAL SPECIFICATION
Format	1640 × 990 × 35 mm
Weight	18.3kg
Glass	White toughened safety glass, 3.2 mm
Backsheet	Composite film
Frame	Anodized aluminum profile
Cell Orientation	60 cells (6 × 10)
Junction Box	Rated current 12A, IP 67,TUV&UL
Cable	Length 900 mm, 1 × 4 mm²
Connector	MC 4/ compatible with MC 4

ELECTRICAL CHARACTERISTICS
STC: Irradiance 1000W/m², Cell Temperature 25°C, Air Mass AM1.5. *Measuring tolerance: ±3%.
Power Class		[W]	260	265
Power at MPP²	PMPP	[W]	260	265
Short Circuit Current*	ISC	[A]	8.95	9.01
Open Circuit Voltage*	VOC	[V]	37.7	37.8
Current at MPP*	IMPP	[A]	8.58	8.69
Voltage at MPP*	VMPP	[V]	30.3	30.5
Efficiency²	η	[%]	≥16.01	≥16.01

WARRANTY

Please refer to product warranty for details

10 year Product Workmanship Warranty

25 year Linear Power Warranty

The power output shall not be less than 97.5% of the minimum power output stated in the product data sheet in the first year of the product's life cycle.The loss of power output shall not exceed 0.7% per year thereafter,ending with 80.7% in the 25th year.

QUALIFICATIONS AND CERTIFICATES

IEC61215/IEC61730/UL1703/IEC61701/IEC62716

ISO 9001: Quality Management System

ISO 14001: Environmental Management System

ISO14064: Greenhouse gases Emissions Verification

OHSAS 18001: Occupation Health and Safety

Management System
