Eco Friendly 290 W C Grade Solar Panels MC4 Compatible Long Life Span

Factory Price High Quality 60P 290W Monocrystalline Silicone Solar Panel

Technical Parameters:

Type	JBF60P270W
Rated Maximum Power-Pmax	270W
Tolerance	0~+5
Maximum Power Current-Vmp	31.3V
Maximum Power Current-Imp	8.63A
Open Circuit Boltage-Voc	38.4V
Short Circuit Current-Isc	9.2A
Module Efficiency-ηm	16.6%
Standard Test Conditions	AM=1.5,1000W/m2
Solar Cell	60 cells(156156mm Poly Crystalline)in 610 matrix connected in series
Junction Box	Potted,IP67,1500V
Cable Type	Photovoltaic Technology Cable 4mm2(12AWG),1000m
Connector Type	IP67,MC4 Compatible
Max.Series Fuse Rating	15A
Max.System Voltage	1500V
Nominal Operating Cell Temperature	45±2ºC
Operating Temperature	-40~+85ºC
Temperature Coefficient of Pmax Pmax	-0.443%/ºC
Temperature Coefficient of Voc Voc	-0.3357%/ºC
Temperature Coefficient of Isc Isc	0.0448%/ºC

Mechanical&Packing Data

Module Dimensions	164099235mm
Weight	18KG
Construction	Superstrate:High transmission 3.2mm tempered low iron glass; Substrate:White Back Sheet;Encapsulant:Fast Cure EVA
Frame	Clear anodized aluminum alloy type 6063T5;Color:silver
Modules per Box	30 pcs per carton
Container Loading Capacity	840 pcs per 40ft High Cubic Container

Product Feature:
1. High cell efficiency with quality silicon materials for long term output stability and reliability.
2. High transmittance low iron tempered glass with enhanced stiffness and impact resistance
3. Unique frame design with high mechanical strength for easy Installation.
4. Advanced encapsulation material with multiplayer sheet lamination to provide efficient
protection from the severest environmental conditions, PET sheet imported from Toyo Japan with advanced encapsulating material
5. Outstanding electrical performance under high temperature and low irradiance conditons
6. Excellent performance in harsh weather,Outstanding electrical performance under high temperature and low irradiance
7. Strictly quality control ensure the stability and reliability, totally 30 QC procedures.

Solar Module Application

1. large or small on-grid or off-grid solar power station
2. commercial/ industrial building roof-top/ ground mounting system
3. residential/ small home power system.
4. solar refrigerator, solar air condition, solar heater, solar lighting system
5. solar street light, solar garden light and many fields of environment protection.
