Commercial Blue C Grade Solar Panels , Off Grid Solar Modules 3 % Tolerance

Ask Lasest Price
Brand Name :	Yingli/Jinko
Certification :	ISO9001/CE
Price :	Negotiation
Payment Terms :	T/T、L/C、West Union
Supply Ability :	5000000 Watt/Watts per Month
Delivery Time :	Shipped in 7 days after payment

Add to Cart

Product Details
Company Profile

Commercial Blue C Grade Solar Panels , Off Grid Solar Modules 3 % Tolerance

Product Description

305W Poly Solar Module with TUV&CE certificate
Features:
High conversion efficiency
Low power tolerance of 0~+3%
Low degradation under light exposure
Can withstand high wind-pressure, snow load and extreme temperature
Passing IEC 61215 2400Pa mechanical load test

Quality and Safety:

10-year warranty on product materials and processing technology
Power output warranty: 10 years: 90%, 25 years: 80%
ISO 9001: 2008(Quality Management System) certified factory
IEC61215, IEC61730, MCS CEC certified products
TUV, CE conformity

Applications

On-grid residential roof-tops
On-grid commercial/industrial roof-tops
Solar power plants
Off-grid system
Other on-grid applications

Specifications

Model Type	ODA305-36-P
Peak Power(Pmax)	305.00
Maximum Power Voltage(Vmp)	37.58
Maximum Power Current(Imp)	8.12
Open Circuit Voltage(Voc)	44.64
Short Circuit Current(Isc)	8.68
Module Efficiency (%)	15.72
Maximum System Voltage(V)	1000
Maximum Series Fuse Rating(A)	15

Power Tolerance	0~+3%
Pmax Temperature Coefficients(W/ºC)	-0.450%
Voc Temperature Coefficients(V/ºC)	-0.350%
Isc Temperature Coefficients(A/ºC)	+0.040%
NOCT Nominal Operating Cell Temperature(ºC)	47±2
Operating and Storage Temperature(ºC)	-40~+85
Standard Test Condition(STC)	1.000W/;AM 1.5;25+/-2ºC

Mechanical characteristics & Packing

Cell Type	Poly-crystalline 156×156mm
No. of Cells	72(6×12)
Dimensions	1956×992×45mm
Weight	23.00kgs
Front Glass	3.2mm high transmission,low iron,tempered glass
Frame	Anodized Aluminium Alloy
Junction box	IP65 Rated
Output cables	2.5mm² Length 90mm, MC4 connector
1x20'	12pallets/244pcs
1x40'HQ	24pallets/564pcs

Product Description

Solar Module Application

1. large or small on-grid or off-grid solar power station
2. commercial/ industrial building roof-top/ ground mounting system
3. residential/ small home power system.
4. solar refrigerator, solar air condition, solar heater, solar lighting system
5. solar street light, solar garden light and many fields of environment protection.
