18 Kg Monocrystalline B Grade Solar Panels 3.2 Millimeter Tempered Glass

Suzhou Jun Hui Import and export trade Co., Ltd.
Contact Now
    Buy cheap 18 Kg Monocrystalline B Grade Solar Panels 3.2 Millimeter Tempered Glass from wholesalers

    Buy cheap 18 Kg Monocrystalline B Grade Solar Panels 3.2 Millimeter Tempered Glass from wholesalers
    • Buy cheap 18 Kg Monocrystalline B Grade Solar Panels 3.2 Millimeter Tempered Glass from wholesalers
    • Buy cheap 18 Kg Monocrystalline B Grade Solar Panels 3.2 Millimeter Tempered Glass from wholesalers

    18 Kg Monocrystalline B Grade Solar Panels 3.2 Millimeter Tempered Glass

    Ask Lasest Price
    Brand Name : Yingli/Jinko
    Certification : ISO9001/CE
    Price : Negotiation
    Payment Terms : T/T、L/C、West Union
    Supply Ability : 5000000 Watt/Watts per Month
    Delivery Time : Shipped in 7 days after payment
    • Product Details
    • Company Profile

    18 Kg Monocrystalline B Grade Solar Panels 3.2 Millimeter Tempered Glass

    High Efficiency Solar Panel Monocrystalline Solar Panel Manufacturers In China


    SOLAR PANEL / PV MODULE:


    1. Use A grade solar cell, high efficiency;

    2. High transmittance, low iron tempered glass with enhanced stiffness and impact resistance;

    3. Anodized aluminum alloy frame with high mechanical strength for easy installation;

    4. Anti-aging EVA and high flame resistant Back Sheet, to provide long-life and enhanced cell performance;

    5. Outstanding electrical performance under high temperature and low irradiance conditions;

    6.100% apply EL(electroluminescence) technology;

    7.5 years limited warranty, 10 years limited warranty for 90% power output, 25 years limited warranty for 80% power output;

    8. With CE, TUV, ISO9001: 2008 certificate;

    Product Description

    Maximum power: 300Wp

    Maximum working voltage: 36.2V

    Maximum working current: 8.28A

    Open circuit voltage: 43.4V

    Short-circuit current: 9.27A

    Cell number: 72pcs (156*156mm)

    Cell dimensions: 156*156mm

    Solar panel dimensions: 1956× 992 × 40mm

    Maximum system voltage: 1,000V

    Operating temperature: -40 to 85°C

    Surface maximum loading capacity: (surface can withstand the maximum pressure) 60m/s (200kg/sq.m)

    Allowable hail load (hail stress testing) steel ball fall down from 1m height

    Weight of each solar panel: 21.4kg

    Connection box type: PV-JB001 (TUV)

    Cable type: with TUV mark

    Cable length: 900mm

    Output power tolerance: ± 3%

    Frame material: aluminum

    Standard test conditions (STC): 1,000W/m² AM1.525°C

    10 years product warranty and 25 years 80% of power

    Fill factor: e 72%

    20-foot container quantity: 288pcs

    40-foot container quantity: 624pcs


    2577196940_79337959.jpg2577199436_79337959.jpg2577202312_79337959.jpg2581959571_79337959.jpg2581962788_79337959.jpg2581965296_79337959.jpg100W detail.jpg
