    Multifunction Stock Amorphous Solar Panel 0.13 Inch Glass For Industry

    Ask Lasest Price
    Brand Name : Yingli/Jinko
    Certification : ISO, CE, TUV,CQC
    Price : Negotiation
    Payment Terms : T/T、L/C、West Union
    Supply Ability : 5000000 Watt/Watts per Month
    Delivery Time : Shipped in 7 days after payment
    • Product Details
    • Company Profile

    Multifunction Stock Amorphous Solar Panel 0.13 Inch Glass For Industry

    Monocrystalline / Polycrystalline / Amorphous Solar Panels For Solar Power Plants,stations, Home


    Product Description


    Mechnical specification

    Cell Type

    Poly crystalline 156*156 mm

    Number of cells

    60(6*10)

    Dimensions

    1640*990*40mm

    Weights

    21kg

    Front Glass

    3.2 mm tempered low iron alloy

    Frame Material

    Clear anodized aluminium frame

    Junction Box

    IP 65 ,With bypass diodes

    Connector

    MC4 compatible

    Output Cables

    TUV ,± lengh 900mm

    Electrical characteristics

    Maximum Power at STC (Pmax)

    245w

    Short circuit current (Isc)

    8.74A

    Open ciruit voltage(VOC )

    37.3V

    Maximum power Current (IMMP)

    8.215A

    Maximum Cell Efficiency

    30.5V

    Module Efficiency

    15.4%

    Power Lolerance

    1%-3%

    STC:irradiance 1000w /m2 ,module temp. 25ºC

    Temperature charcteristics

    Norminal operating cell Temperature (NOTC)

    45ºC±2ºC

    Temperature Coefficient of pmax

    -0.44%ºC

    Temperature Coefficient of voc

    -0.34%ºC

    Temperature Coefficient of isc

    0.06%ºC

    system integration prameters

    Maximum system voltage

    VDC 1000v

    Maximum series fuse

    15A

    increased snowload acc.to IEC 61215

    5400 pa

    operating temperature

    -45 to +85ºC

    system integration prameters

    Maximum system voltage

    VDC 1000v

    Maximum series fuse

    15A

    increased snowload acc.to IEC 61215

    5400 pa

    operating temperature

    -45 to +85ºC

    Number Of bypass diodes

    3 or 6


    2017 New Style High Power Maximum Power Solar Panel

    2017 New Style High Power Maximum Power Solar Panel

    2017 New Style High Power Maximum Power Solar Panel
