Energy Saving Polycrystalline Solar Panel 1956*992*45 Mm Long Life Span

Suzhou Jun Hui Import and export trade Co., Ltd.
Contact Now
    Buy cheap Energy Saving Polycrystalline Solar Panel 1956*992*45 Mm Long Life Span from wholesalers

    Buy cheap Energy Saving Polycrystalline Solar Panel 1956*992*45 Mm Long Life Span from wholesalers
    • Buy cheap Energy Saving Polycrystalline Solar Panel 1956*992*45 Mm Long Life Span from wholesalers

    Energy Saving Polycrystalline Solar Panel 1956*992*45 Mm Long Life Span

    Ask Lasest Price
    Brand Name : Yingli/Jinko
    Certification : ISO9001/CE
    Price : Negotiation
    Payment Terms : T/T、L/C、West Union
    Supply Ability : 5000000 Watt/Watts per Month
    Delivery Time : Shipped in 7 days after payment
    • Product Details
    • Company Profile

    Energy Saving Polycrystalline Solar Panel 1956*992*45 Mm Long Life Span

    Used for off-Grid Solar System 300wp Polycrystalline Solar Panels


    Specs


    Model

    ZCM6-72P-310W

    Electrical Characteristics

    Maximum Power [Pmax]

    310W

    Power Tolerance

    +/-3%

    Maximum Power Voltage [Vmp]

    37.1V

    Maximum Power Current [Imp]

    8.38A

    Short-Circuit Current [Isc]

    8.78A

    Open-Circuit Voltage [Voc]

    45.5V

    Module Efficiency

    15.98%

    Max. System Voltage

    1000VDC

    Cell Size and Series

    Mono 156*156 72pcs (6*12)

    Temperature Coefficient of Pmax

    - 0.47% / º C

    Temperature Coefficient of Voc

    - 0.35% / º C

    Temperature Coefficient of Isc

    0.05% / º C

    Mechanical Characteristics

    Dimension (mm)

    1956*992*45

    Frame

    Anodized Aluminium Alloy

    Glass

    3.2mm,High Transmission,Tempered Glass

    Junction box & Cable

    IP65 Rated weatherproof connectors
    Cable: TUV 1x4.0mm2 / UL12AWG,Length:900mm

    Weight

    22.0Kgs


    Industry-leading Warranty:


    Warranty on material and workmanship: 10 years
    Guaranteed output of 90% after 12 years and 80% after 25 years.


    Features:


    High conversion efficiency
    Low power tolerance of 0~+3%
    Low degradation under light exposure
    Can withstand high wind-pressure, snow load and extreme temperature
    Passing IEC 61215 5400Pa mechanical load test

    Quality and Safety:


    10-year warranty on product materials and processing technology
    Power output warranty: 10 years: 90%, 25 years: 80%
    ISO 9001,ISO14001,OHSAS18001(Quality Management System) certified factory
    TUV, IEC61215, IEC61730, CE certified products

    Applications:


    On-grid residential roof-tops
    On-grid commercial/industrial roof-tops
    Solar power plants
    Off-grid system
    Other on-grid applications

    Packing and Delivery:

    1. Packing: 2pcs/ctn and 23ctns/pallet
    2. Delivery time: 15 days

    Specification:

    250W Poly Crystalline Solar Panel

    Quality Energy Saving Polycrystalline Solar Panel 1956*992*45 Mm Long Life Span for sale
