Energy Saving Monocrystalline Silicon Solar Panels 1956x992x40 Millimeter

Product Categories

Suzhou Jun Hui Import and export trade Co., Ltd.

Contact Now

Ask Lasest Price
Brand Name :	Yingli/Jinko
Certification :	ISO CE
Price :	Negotiation
Payment Terms :	T/T、L/C、West Union
Supply Ability :	5000000 Watt/Watts per Month
Delivery Time :	Shipped in 7 days after payment

Add to Cart

Powerwell Solar 360W Highest Efficiency Mono Photovoltaic PV Solar Panels

Product Description

Modle	BW-SM330M72	BW-SM335M72	BW-SM340M72	BW-SM345M72	BW-SM350M72	BW-SM355M72	BW-SM360M72
Rated Maximum Power at STC	330	335	340	345	350	355	360
Maximum Power Voltage (Vmp)	38.2V	38.5V	38.7V	38.9V	39.1V	39.3V	39.5V
Maximum Power Current (Imp)	8.61A	8.70A	8.79A	8.87A	8.94A	9.04A	9.12A
Open Circuit Voltage ( Voc)	46.5V	46.8V	47.1V	47.3V	47.5V	47.8V	48.0V
Short Circuit Current (Isc)	9.05A	9.15A	9.24A	9.31A	9.38A	9.45A	9.51A
Module Efficiency	17.01%	17.26%	17.52%	17.78%	18.01%	18.31%	18.57%
Power Tolerance	0~+3%	0~+3%	0~+3%	0~+3%	0~+3%	0~+3%	0~+3%
STC: Irradiance 1000W/m², Module Temperature 25°c, Air Mass 1.5
Mechanical Parameters
Cell Type			Mono-crystalline 156x156mm (6inch)
No. of Cells			72 (6x12)
Dimension			1956x992x40mm
Glass			3.2mm, High Transmission, Low Iron, Tempered Glass
Junction Box			IP65&IP67 Rated
Output Cable			Section Size: 4mm² , Length: 900mm
Frame			Anodized Aluminum Alloy
No. of Bypass Diodes			3&6
Connector			MC4 Compatible
Working Conditions
Maximum System Voltage			DC 1000V(IEC) / 1500V(IEC) / 600V(UL)
Operating Temperature			-40°c~+85°c
Maximum Series Fuse			15A
NOCT			45±2°c
Application Class			Class A
Temperature Coefficient
Temperature Coefficient of Pmax			-0.40%/°c
Temperature Coefficient of Voc			-0.30%/°c
Temperature Coefficient of Isc			+0.05%/°c

Good Quality Padan 60 PCS 50W-300W Panda Mono Solar Cell and Panel

Shipping: Within 15 workdays after order confirmed
Good Quality Padan 60 PCS 50W-300W Panda Mono Solar Cell and Panel

OUR Services :

1. Rich experience in manufacturing and exporting electric equipment.

2. High quality and competitive price.

3. Strict quality control and excellent after-sales service.

4. Manufacturing according to customers requirements is available.
