Mechanical Parameters (solar panels No and the arrange can be customized )

Cell Type

mono-crystalline 156x156mm (6inch)

No. of Cells

72 (6x12)

Pmax

300w

Vmp

35.80v

IMP

8.38V

VOC

42.96V

ISC

9.22A

Module efficency

18.48%

Dimension

1025x675x30mm

Glass

32mm, High Transmission, Low Iron, Tempered Glass

Junction Box

≥ IP67

Output Cable

UV resistant solar cable ,900mm-section 4.0mm2(12AWG)

Frame

Double Anodized Aluminum Alloy

No. of Bypass Diodes

3&4

Connector

MC4 / IP67 /YT08-1/IP67/Amphenol H4/IP68 Compatible

Working Conditions

Maximum System Voltage

DC 1000V

Operating Temperature

-40°c~+85°c

Maximum Series Fuse

15A

NOCT

45±2°c

Application Class

Class A

Temperature Coefficient

Temperature Coefficient of Pmax

-0.42%/°c

Temperature Coefficient of Voc

-0.32%/°c

Temperature Coefficient of Isc

+0.06%/°c

All of the cell type can be PV or assembled as customer requirment and application
