    18 Kg Grade A Poly Solar Panel GSPV200M Type With IP65 Junction Box

    Ask Lasest Price
    Brand Name : Yingli/Jinko
    Certification : ISO9001/CE
    Price : Negotiation
    Payment Terms : T/T、L/C、West Union
    Supply Ability : 5000000 Watt/Watts per Month
    Delivery Time : Shipped in 7 days after payment
    • Product Details
    • Company Profile

    18 Kg Grade A Poly Solar Panel GSPV200M Type With IP65 Junction Box


    Product Description


    Module Type

    GSPV200M

    Origin

    Nanjing,Jiangsu, China

    Brand

    LANG

    Pmax

    260w

    Current at Pmax (Imp)

    8.45A

    Voltage at Pmax (Vmp)

    30.8V

    Short-Circuit Current ( Isc )

    8.89A

    Open-Circuit Voltage ( Voc )

    37.4V

    Cell type

    156*156 poly-crystalline

    Cell Configuration

    60 (6*10) PCS in series

    Dimension

    1640*992*35mm

    weight

    18KG

    Front Glass

    3.2mm,high transmission,Low iron,tempered glass

    Junction Box

    IP65 Rated

    Cable

    4.0 mm ² Length:900mm

    Frame

    Anodized aluminium-alloy

    Nominal Operating Cell Temperature(NOCT)

    45 ±2 ºC

    Power temperature Coefficient

    -0.44% K

    Open-Circuit Voltage temperature Coefficient

    -0.33%/ K

    Short-Circuit Current temperature Coefficient

    0.06%/ K

    All Technical Data at STC

    AM1.5 E=1000W/ m ² Tc=25 ºC

    Label&Logo

    OEM

    Warranty

    10 years limited product warranty and 25 years limited power guarantee.


    320W Poly Solar Panel Power for Green Energy
    320W Poly Solar Panel Power for Green Energy
    FAQ

    Is solar power difficult to use?
    Although the production of solar panels incorporates a high-tech manufacturing process, it is really very easy to use a photovoltaic system. Solar panels have no moving parts to wear out, they can be used alone or in combination with other energy sources, and they are silent, reliable and long lasting.
    What can you power with Photovoltaics?
    A properly designed photovoltaic system can supply electricity for many applications, from small remote lighting needs to megawatts of power for large utility companies. An advantage of photovoltaic power is that it can do anything a traditional power generator can do, only without consuming pollution-causing fuel, or requiring noisy motors.
    What is a PV system?
    A PV system consists of all the equipment and materials needed to generate solar energy, including solar panels (often called modules), a support structure, wiring, an inverter, a meter and other equipment as required by a specific application. JUST-SOLAR's PV system for commercial buildings, and ET Solar system for residential uses are examples of complete PV systems.
    What is a solar module?
    Solar modules are series of solar cells, wired together and enclosed protect them from the environment. They are often referred to as in self-contained glass units to solar panels as well.
    How do solar cells work?
    Solar cells are solid-state devices in which photons (or packets of light) collide with atoms. This process transforms the resulting into electrons. These electrons flow into wires connected to the cell, thus providing electric current to appliances, lighting systems or other electrical loads; and all of the power comes directly from the sun.
    What is Photovoltaic Power?
    Photovoltaic (PV) power is a term used to describe the process of converting sunlight into electricity with solar cells. These cells are specially constructed from semiconductor materials, and are treated to generate a flow of electricity when sunlight shines on them.


    320W Poly Solar Panel Power for Green Energy
