Model

YS285P-72

YS290P-72

YS295P-72

YS300P-72

YS305P-72

YS310P-72

YS320P-72

Rated Maximum Power at STC

285W

290W

295W

300W

305W

310W

320W

Maximum Power Voltage (Vmp)

35.6V

35.8V

36.1V

36.3V

36.5V

36.7V

37.2V

Maximum Power Current (Imp)

8.01A

8.11A

8.19A

8.29A

8.38A

8.45A

8.61A

Open Circuit Voltage ( Voc)

44.6V

44.8V

45.1V

45.3V

45.6V

45.9V

46.4V

Short Circuit Current (Isc)

8.66A

8.72A

8.78A

8.84A

8.91A

8.96A

9.05A

Module Efficiency

14.76%

15.02%

15.28%

15.54%

15.81%

16.06%

16.58%

Power Tolerance

0~+3%

0~+3%

0~+3%

0~+3%

0~+3%

0~+3%

0~+3%

STC: Irradiance 1000W/m², Module Temperature 25°c, Air Mass 1.5

Mechanical Parameters

Cell Type

Poly-crystalline 156x156mm (6inch)

No. of Cells

72 (6x12)

Dimension

1956x990x40/45/50mm

Glass

3.2mm, High Transmission, Low Iron, Tempered Glass

Junction Box

IP65&IP67 Rated

Output Cable

Section Size: 4mm² , Length: 900mm

Frame

Anodized Aluminum Alloy

No. of Bypass Diodes

3&6

Connector

MC4 Compatible

Working Conditions

Maximum System Voltage

DC 1000V(IEC) / 1500V(IEC) / 600V(UL)

Operating Temperature

-40°c~+85°c

Maximum Series Fuse

15A

NOCT

45±2°c

Application Class

Class A

Temperature Coefficient

Temperature Coefficient of Pmax

-0.41%/°c

Temperature Coefficient of Voc

-0.31%/°c

Temperature Coefficient of Isc

+0.06%/°c
