product description:
Whenever the conditions are requiring a more robust solution, our
TwinMAX modules are the right choice. By the additional layer glass
on the rear side, our modules are much more robust and reliable.
Carefully chosen materials, state of the art solar cells and our
experience in manufacturing ensure in addition the high product
quality.
Feature:
1.High Power Density
High e ciency, four busbar multicrystalline silicon solar cells
with high transmission and textured glass deliver a module e ciency
of up to 16.6%, minimizing installation costs and maximizing the
kWh output of you systemper unit area.
2.Extended Size
Our large-format module facilitates system-level cost savings
through reduced handling and installation times.
3.Durability
Durable TwinMAX modules, independently tested for harsh
environmental conditions such as exposure to salt mist, ammonia, or
known PID risk factors.
4.PID Resistant
Tested at 85°C temperature and 85% relative humidity for 96 hrs
beyond IEC standards, TwinMAX modules have demonstrated their
resistance against PID, which provides greater investment security.
Electrical performance:
Electrical | parameters | at | standard | test | conditions | ( | STC | ) |
Module type | YLXXXPG2536L-1 | ( | XXX=Pmax | ) |
|
|
|
|
Power output | Pmax | W | 325 | 320 | 315 | 310 | 305 | 300 |
Power output tolerance | Pmax | W | 0/+5 |
|
|
|
|
|
Module efficiency | nm | % | 16.6 | 16.4 | 16.1 | 15.9 | 15.6 | 15.4 |
Voltage at Pmax | Vmpp | V | 37.3 | 30.0 | 36.8 | 36.3 | 36.1 | 35.8 |
Current at Pmax | Impp | A | 8.72 | 8.64 | 8.56 | 8.53 | 8.45 | 8.37 |
Open-circuit voltage | Voc | V | 46.3 | 46.0 | 45.7 | 45.6 | 45.4 | 45.2 |
Short-circuit current | Isc | A | 9.24 | 9.18 | 9.12 | 8.99 | 8.93 | 8.86 |
General characteristics:
Dimensions (L/W/H) | 1968mm/992mm/6mm |
Weight | 27.3kg |
Packaging specifications:
Number of modules per pallet | 33 |
Number of pallets per 40' container | 22 |
Packaging pallets dimensions | 2070mm/1165mm/1195mm |
Pallet weight | 975kg |
Efficiency 270W solar panel
1. Low voltage-temperature coefficient allows higher power output
at high-temperature condition.
2. High efficient, high reliable solar cells ensure our product
output stability.
Benefits of solar panel
1. Manufactured in an ISO9001:2008 certified plant
2. High efficiency, high safety, high reliability
3. Output power tolerance of 0 / + 5
Warranty
1. 10-years limited warranty on materials and workmanship
2. 25-years limited warranty on power output: 10 years/90%, 25
years/80%
